Data sheet
- Brand
- SANDRETTO
- Model
- SERIE 9 285/100
- Year
- 2002
- Clamping force
- kN 1000
- Injection volume
- Distance b/w tie-bars
- mm.415x415
- Screw diameter
- mm.33
- Pressure on material
- bar 2006
- Clamping stroke
- mm.410
- Mould thickness
- mm.100÷460
- Control type
- Clamping system
- TOGGLE
- Total installed power
- Motor power
Quick Compare
Product |
copy of SANDRETTO SERIE 9 S 285/100
|
SANDRETTO SERIE MICRO 107/50 (R)
|
copy of SANDRETTO SERIE 9 S 285/100
|
copy of SANDRETTO SERIE 8 430/110
|
Price |
||||
Rating |
||||
Description |
||||
Brand |
SANDRETTO | SANDRETTO | SANDRETTO | |
Model |
SERIE 9 285/100 | Serie Micro 107/50 | SERIE 9 285/100 | |
Reference |
P.00332 | |||
Year |
2002 | 2000 | 2002 | |
Clamping force |
kN 1000 | kN 500 | kN 1000 | |
Injection volume |
cm³ 54 | |||
Distance b/w tie-bars |
mm.415x415 | mm.415x415 | mm.415x415 | |
Screw diameter |
mm.33 | mm.45 | mm.33 | |
Pressure on material |
bar 2006 | bar 1980 | bar 2006 | |
Clamping stroke |
mm.410 | mm.450 | mm.410 | |
Mould thickness |
mm.100÷460 | mm.120 min. | mm.100÷460 | |
Control type |
GEFRAN | |||
Clamping system |
TOGGLE | PISTON | TOGGLE | |
Total installed power |
kW 14,3 | |||
Motor power |
kW 11 | |||
Availability |
|
|
|
|
|
|
|
|
|
